R5 Plus Model

Rental R5 Plus Model LED Display


Pixel Pitch
1.56mm / 2.976mm / 3.91mm (Indoor), 2.976mm / 4.81mm (Outdoor)
LED Type
SMD1212 / SMD1515 / SMD2020 (Indoor), SMD1415 / SMD1921 (Outdoor)
Pixel Density
410,881 dots/m² (Indoor), 147,456 dots/m² / 43,264 dots/m² (Outdoor)
Brightness
≤800 nits (Indoor), ≥4000 nits (Outdoor)
IP Rating
IP45 (Indoor), IP65 (Outdoor)
Cabinet Size
1000 x 500 x 85mm
Maximum Power Consumption
600W/m² (Indoor), 750W/m² (Outdoor)
Operating Temperature
-20℃ ~ +65℃
